Air Cooled (Mini) Heat Pumps

  • 7.8 ÷ 40.8 kW / 2.22 ÷ 11.60 Tons

  • 8.6 ÷ 44.5 kW / 2.45 ÷ 12.65 Tons

  • 3.1 EER / 3.5 COP

  • Compressor - 5 year limited ; Other parts - 1 year limited

  • R410A, R407C,R22

  • Roraty & Scroll type; HITACHI, Panasonic, Daikin, MITSUBISHI,Copeland

  • High efficiency plate heat exchanger

  • High efficiency finned copper pipe heat exchanger

  • 230V/1Ph/50Hz and 380V/3Ph/50Hz (400V/415V/3Ph/50Hz, 230V/380V/460V/3Ph/60Hz as option)


Product Overview

—— Product Description ——

Withair® heat pump is a very intelligent heat pump system with flexible capacity output. It could adjust heating capacity output automatically according to requirements.It is much more energy-saving with a long lifespan.


Withair® multifunction air source heat pump provides energy-efficient room heating and cooling for residential and small commercial application. Using free renewable energy from the air ,the units are highly efficient with low running costs, low carbon emission and are able to be integrated with energy systems such as solar heater and boiler.

—— The key advantages Include ——


● ECO friendly refrigerant R410A,R407C.

● Intelligent defrost totally.
● Multi self-protection  functions, such as: high & low pressure, high temperature, water flow and antifreeze protection.
● A
dvanced & world-famous hermetic compressor high-efficiency, low-noise and low-vibration operation.
● Hydrophilic and corrosion-resistant material ensures adaptability to poor weather.
● Uses advanced hermetic inverter compressor high-efficiency, low-noise, and low-vibration operation.
● Remote monitoring and control features enable the unit’s operational schedule to be set via internet or phone.
● Using modular networking technology, the operation of individual modules can be coordinated according demand.
● Standalone subsystems enable maintenance of individual subsystems without affecting the continued operation of the rest.
● Unique heat exchanger protection technology, increases heat exchange efficiency to 30% above that of conventional heat exchangers.

—— You May Like ——

Withair® Air Cooled Heat Pump Chiller (1)   Concealed Type Fan Coil Unit Withair® Hydraulic module     Withair® Hydraulic balance distributor       Withair® Insulation pipe         Termostat controls (2)

Air Cooled Heat Pump        +       Fan Coil Unit        +        Hydraulic Module   +   Hydraulic balance distributor   +   Insulation pipe     +      Thermostat

Physical Data


Physical Data of Withair® Air Cooled (Mini) Heat Pumps.png


1.    Standard cooling work condition: entering chilled water temperature 12℃, leaving temperature 7℃;dry bulb temperature 35℃,wet bulb temperature 24℃;
2.    Standard heating work condition: entering hot water temperature 40℃,leaving temperature 45℃; dry bulb temperature 7℃,wet bulb temperature 6℃.
3.    All models, sizes, dimensions, and specifications are subject to change without prior notice, please refer to nameplates for the most accurate specifications

Packaging & Transportation


● Four steps of pakacges, plastic film, foam, carton and plywood for stable transporation.

● 100% test before deliverying products.
● Item shipped in 25 working days against payment depends on the quantity.
● Products catalogue, installation & operation manual will be sent together.
● Tracking number will be sent to customer as soon as we ship the products.
● Ocean shipping, railway shipment and air transportation are acceptable according to customer demand.

Withair® provides two styles package for different transporation modes:

(1). St andard package(free of charge): unit is wrapped with plastic film, foam and carton, which is suitable for container shipment & a few transshipment cargo;
          withair heat pump_carton package-
(2). Special pac kage(extra charge): unit is wrapped with plastic film and wooded box, which is suitable for bulk cargo transporation;
       Withair Heat Pumps package by wooden box
